| Part Number | TM103XDKP05 |
| Mark | TIANMA |
| Gréisst | 10.3 |
| Applikatioun | Outdoor High Brightn |
| Opléisung | 1920×720 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | TIANMA |
| Modell | TM103XDKP05 |
| diagonal Gréisst | 10.3 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×720 200PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 243.648(H)×91.368(V) mm |
| kontur dim. | 259.84(H)×109.3(V) mm |
| bezel Beräich | - |
| Behandlung | Hard coating, Reflection 5.5% (Typ.) |
| luminance | 1000 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10) |
| Betribssystemer Modus | SFT, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 75% NTSC |
| Liichtquell | WLED [9S4P] , 10K hours , W/O Driver |
| Gewiicht | 300g (Typ.) |
| entworf fir | Outdoor High Brightness Automotive Display |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
