| Part Number | TM080VDSP03 |
| Mark | TIANMA |
| Gréisst | 8.0 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1200×1920 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | 7S3P |
| Interface | |
| Panel Mark | TIANMA |
| Panel Gréisst | 8.0" |
| Resolutioun | 1200(RGB)×1920, WUXGA, 283PPI |
| Affichage Beräich | 107.64(W)×172.224(H) mm |
| Kontur Gréisst | 114.58(W)×184.09(H) ×3.95(D) mm |
| Hellegkeet | 390 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 60% NTSC |
| Frequenz | 60Hz |
| Panel Gewiicht | TBD |
| Input Volt | 3.3V (Typ.)(VCI) |
| Ëmwelt | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -15 ~ 70 °C |
| Panel Modell | TM080VDSP03 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Hard coating |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Display Modus | SFT, Normally Black, Transmissive |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Lampe Typ | 7S3P WLED |
| Touchscreens | Without |
| Applikatioun | Pad & Tablet |
