| Part Number | TM060JVZG02 |
| Mark | TIANMA |
| Gréisst | 6.0 |
| Applikatioun | Medical Imaging |
| Opléisung | 800×1280 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | 8S2P WLED , 30K hours , No Driver |
| Interface | MIPI |
| Fabrikant beschwéiert | TIANMA |
| Modell Numm | TM060JVZG02 |
| Écran Gréisst | 6.0 inch |
| Écran Typ | LCM , a-Si TFT-LCD |
| Pixel Zuel | 800(RGB)×1280 (WXGA) 251PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 80.76 × 129.216 (H×V) |
| Kontur (mm) | 104.16 × 152.62 × 6.5 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Antiglare (Haze 1%) |
| luminance | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 800 : 1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Äntwert | 25 (Typ.)(Tr+Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | SFT, Normally Black, Transmissive |
| Faarfdéift | 16.7M 68% NTSC |
| mass | TBD |
| benotzt fir | Medical Imaging |
| Erfrëschungsrate | - |
| touchscreen | PCAP |
| Signal Typ | MIPI (4 data lanes) , 45 pins FPC |
| Spannungsversuergung | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
