| Part Number | TM040YDH51 |
| Mark | TIANMA |
| Gréisst | 4.0 |
| Applikatioun | Mobile Phone |
| Opléisung | 480×800 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 600:1 |
| Faarwen | 16.7M |
| Géigeliicht | 7S1P WLED , No Driver |
| Interface | |
| Fabrikant beschwéiert | TIANMA |
| Modell Numm | TM040YDH51 |
| Écran Gréisst | 4.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 480(RGB)×800 (WVGA) 235PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 51.84 × 86.4 (H×V) |
| Kontur (mm) | 57.24 × 98.3 × 2.3 (H×V×D) |
| Bezel Beräich (mm) | 52.84 × 87.4 (H×V) |
| Behandlung | Clear |
| luminance | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 600 : 1 (Typ.) (TM) |
| Vue Wénkel | 70/70/70/60 (Typ.)(CR≥10) |
| Äntwert | 20 (Typ.)(Tr+Td) ms |
| gutt Vue op | 6 o'clock |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 16.7M 60% NTSC |
| mass | TBD |
| benotzt fir | Mobile Phone |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
