| Part Number | TM030LDHT13 |
| Mark | TIANMA |
| Gréisst | 3.0 |
| Applikatioun | Handheld & PDA |
| Opléisung | 240×400 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | |
| Faarwen | - |
| Géigeliicht | WLED |
| Interface | |
| Fabrikant beschwéiert | TIANMA |
| Modell Numm | TM030LDHT13 |
| Écran Gréisst | 3.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 240(RGB)×400 (WQVGA) 156PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 38.88 × 64.8 (H×V) |
| Kontur (mm) | - |
| Vue Wénkel | - |
| Äntwert | - |
| gutt Vue op | - |
| Aarbecht Modus | ECB, Normally White, Transflective |
| Faarfdéift | |
| mass | - |
| benotzt fir | Handheld & PDA |
| Erfrëschungsrate | - |
| touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
