| Part Number | TM028HDZG59 |
| Mark | TIANMA |
| Gréisst | 2.8 |
| Applikatioun | Mobile Phone |
| Opléisung | 240×320 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 400:1 |
| Faarwen | 65K/262K |
| Géigeliicht | WLED |
| Interface | 16-bit |
| Mark | TIANMA |
| diagonal Gréisst | 2.8 inch |
| Pixel Format | 240(RGB)×320 [QVGA] 141PPI |
| aktiv Beräich | 43.2(H)×57.6(V) mm |
| luminance | 300 cd/m² (Typ.) |
| Vue Richtung | - |
| Vue Wénkel | 70/70/70/58 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 65K/262K 63% NTSC |
| Gewiicht | TBD |
| Frame Taux | - |
| Interface Typ | 16-bit 8080 parallel , 37 pins FPC |
| Stroumversuergung | 2.7/3.3V (Min./Max.)(VCI/VCC1/VCC2) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| Modell | TM028HDZG59 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 50(H)×69.2(V) mm |
| Kontrast Verhältnis | 400:1 (Typ.) (TM) |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Liichtquell | WLED [1S4P] , W/O Driver |
| entworf fir | Mobile Phone |
| Touch Panel | Without |
