| Part Number | TM024HDHG04 |
| Mark | TIANMA |
| Gréisst | 2.4 |
| Applikatioun | Handheld & PDA |
| Opléisung | 240×320 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | - |
| Géigeliicht | WLED |
| Interface | CPU |
| Panel Mark | TIANMA |
| Panel Modell | TM024HDHG04 |
| Panel Gréisst | 2.4" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 240(RGB)×320, QVGA, 166PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 36.72(W)×48.96(H) mm |
| bezel Ouverture | - |
| Hellegkeet | - |
| Kontrast Verhältnis | 500:1 (Typ.) (TM) |
| Vue Wénkel | 70/70/70/60 (Typ.)(CR≥10) |
| Display Modus | TN, Normally White, Transmissive |
| beschte Vue op | - |
| Äntwert Zäit | 20 (Typ.)(Tr+Td) |
| weisen Faarwen | |
| Lampe Typ | WLED |
| Frequenz | - |
| Touchscreens | Without |
| Panel Gewiicht | - |
| Applikatioun | Handheld & PDA |
| Signal Interface | CPU FPC |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| AM-240320-024DT | Other | 2.4 | 240×320 |
| AMCE002 | Samsung | 2.4 | 240×320 |
| C0240QGLG-T | CMEL | 2.4 | 240×320 |
| DMC-16117A | Kyocera | 2.4 | 16×1 |
| LS024J3LX01 | SHARP | 2.4 | 320×480 |
| LTM024P339 | TOSHIBA | 2.4 | 240×320 |
| RGS24128064YW005 | RiTdisplay | 2.4 | 128×64 |
| TD024THEB5 | TPO | 2.4 | 480×240 |
| TM024HBZ26 | Tianma | 2.4 | 240×320 |
| TM024HDH36 | Tianma | 2.4 | 240×320 |
