| Part Number | TM020GDZ06 |
| Mark | TIANMA |
| Gréisst | 2.0 |
| Applikatioun | Mobile Phone |
| Opléisung | 176×220 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | |
| Fabrikant beschwéiert | TIANMA |
| Modell Numm | TM020GDZ06 |
| Écran Gréisst | 2.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 176(RGB)×220 (QCIF+) 141PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 31.68 × 39.6 (H×V) |
| Kontur (mm) | - |
| Vue Wénkel | 50/50/25/50 (Typ.)(CR≥10) |
| Äntwert | 30/30 (Typ.)(Tr/Td) ms |
| gutt Vue op | 6 o'clock |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 262K 40% NTSC |
| mass | - |
| benotzt fir | Mobile Phone |
| Erfrëschungsrate | - |
| touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
