| Part Number | T550HVD02.3 |
| Mark | AUO |
| Gréisst | 55 |
| Applikatioun | LCTV |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 4000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | T550HVD02.3 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 55 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | AMVA3, Normally Black, Transmissive |
| aktiv Beräich | 1209.6×680.4 mm |
| skizzéieren | 1239.4×712.3 mm |
| Uewerfläch | Antiglare (Haze 2%) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 4000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 6.5 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 120Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (4 ch, 8-bit), 92 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | LCTV |
| HV550WU2-370 | BOE | 55 | 1920×1080 |
| LC550EUF-FFP2 | LG Display | 55 | 1920×1080 |
| LTA550HJ13 | Samsung | 55 | 1920×1080 |
| P546HW03 V0 | AUO | 55 | 1920×1080 |
| T550HVD02.3 | AUO | 55 | 1920×1080 |
| T550HVN01.3 CELL | AUO | 55 | 1920×1080 |
| T550HVN01.5 CELL | AUO | 55 | 1920×1080 |
| T550HVN02.1 | AUO | 55 | 1920×1080 |
| T550HVN04.0 | AUO | 55 | 1920×1080 |
| T550HVN04.1 | AUO | 55 | 1920×1080 |
| HV320WX2-201 | BOE | 31.5 | 1366×768 |
| LC470EUD-SEF2 | LG Display | 47 | 1920×1080 |
| LC470EUN-SEM1 | LG Display | 47 | 1920×1080 |
| LC500EUD-FFF3 | LG Display | 50 | 1920×1080 |
| LTA460HT-LH3 | Samsung | 46 | 1920×1080 |
| LTY400HL03 | Samsung | 40 | 1920×1080 |
| T400HVN01.0 CELL | AUO | 40 | 1920×1080 |
| T420HW08 V0 CELL | AUO | 42 | 1920×1080 |
| V320B1-L01 | Innolux | 32.0 | 1366×768 |
| V460H1-L09 | Innolux | 46 | 1920×1080 |
