| Part Number | T215HVN05.0 CELL |
| Mark | AUO |
| Gréisst | 21.5 |
| Applikatioun | Desktop Monitor TV S |
| Opléisung | 1920×1080 |
| Zesummesetzung | CELL , a-Si TFT-LC |
| Hellegkeet | |
| CR | 3000:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L |
| Interface | LVDS |
| Fabrikant beschwéiert | AUO |
| Écran Gréisst | 21.5 inch |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 102PPI |
| aktiv Beräich (mm) | 476.064 × 267.786 (H×V) |
| Bezel Beräich (mm) | - |
| luminance | 0 cd/m² |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Glas deck | 0.50+0.50 mm |
| Faarfdéift | 16.7M 76% NTSC |
| mass | 415g (Typ.) |
| Erfrëschungsrate | 60Hz |
| Chauffer ic Lëscht | Built-in COF 6 source chips |
| Signal Typ | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Spannungsversuergung | 5.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Modell Numm | T215HVN05.0 CELL |
| Écran Typ | CELL , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 483.864 × 278.386 × 1.41 (H×V×D) |
| Behandlung | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 3000 : 1 (Typ.) (TM) |
| Äntwert | 13/5 (Typ.)(Tr/Td); 28 (Typ.)(G to G) ms |
| Aarbecht Modus | VA, Normally Black, Transmissive |
| transmissivitéit | 3.6% (Typ.)(with Polarizer) |
| benotzt fir | Desktop Monitor TV Sets |
| touchscreen | Without |
| LC215EUE-SDP1 | LG Display | 21.5 | 1920×1080 |
| LM215DB-T02 | PANDA | 21.5 | 1920×1080 |
| LM215DT8A | PANDA | 21.5 | 1920×1080 |
| LM215WF2-SLC1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLC1 | LG Display | 21.5 | 1920×1080 |
| LM215WF5-SLA1 | LG Display | 21.5 | 1920×1080 |
| LTM215HT03 | Samsung | 21.5 | 1920×1080 |
| M215HGE-L10 | Innolux | 21.5 | 1920×1080 |
| T215HVN01.0 | AUO | 21.5 | 1920×1080 |
| T215HVN01.1 | AUO | 21.5 | 1920×1080 |
