| Part Number | STCG057QVLAD-G00 |
| Mark | Kyocera |
| Gréisst | 5.7 |
| Applikatioun | Industrial |
| Opléisung | 320×240 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | Parallel |
| Fabrikant beschwéiert | Kyocera |
| Modell Numm | STCG057QVLAD-G00 |
| Écran Gréisst | 5.7 inch |
| Écran Typ | LCM , a-Si TFT-LCD |
| Pixel Zuel | 320(RGB)×240 (QVGA) 70PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 115.2 × 86.4 (H×V) |
| Kontur (mm) | - |
| Bezel Beräich (mm) | - |
| Behandlung | Glare (Haze 0%) |
| luminance | - |
| Kontrast Verhältnis | 500 : 1 (Typ.) (TM) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥5) |
| Äntwert | 10/25 (Typ.)(Tr/Td) ms |
| gutt Vue op | - |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 262K |
| mass | - |
| benotzt fir | Industrial |
| Erfrëschungsrate | - |
| touchscreen | 4-wire Resistive Touch |
| Signal Typ | Parallel RGB (1 ch, 6-bit) |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
