| Part Number | SP10Q010 |
| Mark | KOE |
| Gréisst | 3.8 |
| Applikatioun | IA |
| Opléisung | 320×240 |
| Zesummesetzung | LCM |
| Hellegkeet | 110 |
| CR | 20:1 |
| Faarwen | Monochrome |
| Géigeliicht | WLED |
| Interface | Parallel Data |
| Panel Mark | KOE |
| Panel Modell | SP10Q010 |
| Panel Typ | FSTN-LCD , LCM |
| Panel Gréisst | 3.8 inch |
| Resolutioun | 320×240 , QVGA |
| Display Modus | STN, Black/White (Negative), Transmissive |
| aktiv Beräich | 76.79×57.59 mm |
| skizzéieren | 94.7×73.3×6 mm |
| Uewerfläch | Glare (Haze 0%) |
| Hellegkeet | 110 cd/m² (Typ.) |
| Kontrast Verhältnis | 20:1 (Typ.) |
| weisen Faarwen | Monochrome |
| Äntwert Zäit | 150/350 (Typ.)(Tr/Td) |
| Vue Wénkel | 80 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| Frequenz | 75Hz |
| Lampe Typ | 1S6PWLEDWithout Driver |
| Signal Interface | Parallel Data (4-bit), 20 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | IA |
| CMD510TT00-C1 | ORTUSTECH | 3.8 | 320×240 |
| DMC-16230NY-LY-EEE-EGN | Kyocera | 3.8 | 16×2 |
| KHS038AA1AA-B70R-57-11 | Kyocera | 3.8 | 240×320 |
| LQ038B3DD01 | SHARP | 3.8 | 320×480 |
| LQ038Q7DB03 | SHARP | 3.8 | 240×320 |
| LQ038Q7DB03A | SHARP | 3.8 | 240×320 |
| LQ038Q7DB03R | SHARP | 3.8 | 240×320 |
| LS038Y3LX01 | SHARP | 3.8 | 480×800 |
| SP10Q010 | KOE | 3.8 | 320×240 |
| TM038QV-67A02A | SANYO | 3.8 | 320×240 |
| A050AVV50R0 | Aptus | 5.0 | 800×480 |
| G084SN03 V0 | AUO | 8.4 | 800×600 |
| G104SN02 V1 | AUO | 10.4 | 800×600 |
| G156HTD01.0 | AUO | 15.6 | 1920×1080 |
| HTW-G320240B2 | Other | 5.7 | 320×240 |
| LQ084S3LG02 | SHARP | 8.4 | 800×600 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| NL6448BC26-15 | NLT | 8.4 | 640×480 |
| NL8048BC19-02 | NLT | 7.0 | 800×480 |
| TCG121SVLQAPNN-AN20 | Kyocera | 12.1 | 800×600 |
