| Part Number | S101WS07 |
| Mark | CDTECH |
| Gréisst | 10.1 |
| Applikatioun | Industrial |
| Opléisung | 1024×600 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 600:1 |
| Faarwen | 16.7M |
| Géigeliicht | 3S6P WLED , 25K hours , No Driver |
| Interface | Parallel |
| Fabrikant beschwéiert | CDTECH |
| Écran Gréisst | 10.1 inch |
| Pixel Zuel | 1024(RGB)×600 (WSVGA) 117PPI |
| aktiv Beräich (mm) | 222.72 × 125.28 (H×V) |
| Bezel Beräich (mm) | 226.34 × 128.1 (H×V) |
| luminance | 200 cd/m² (Typ.) |
| Vue Wénkel | 65/65/55/65 (Typ.)(CR≥10) |
| gutt Vue op | 12 o'clock |
| Faarfdéift | 16.7M |
| mass | TBD |
| Erfrëschungsrate | 60Hz |
| Signal Typ | Parallel RGB (1 ch, 8-bit) , 50 pins FPC |
| Spannungsversuergung | 3.3/10.85/21/-5.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Modell Numm | S101WS07 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 235 × 143 × 5.39 (H×V×D) |
| Behandlung | - |
| Kontrast Verhältnis | 600 : 1 (Typ.) (TM) |
| Äntwert | 6/20 (Typ.)(Tr/Td) ms |
| Aarbecht Modus | TN, Normally White, Transmissive |
| benotzt fir | Industrial |
| touchscreen | Without |
