| Part Number | S046WV01 |
| Mark | CDTECH |
| Gréisst | 4.6 |
| Applikatioun | Industrial |
| Opléisung | 800×320 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | 6S2P |
| Interface | Parallel |
| Panel Mark | CDTECH |
| Panel Modell | S046WV01 |
| Panel Gréisst | 4.6" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 800(RGB)×320, 188PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 108(W)×43.2(H) mm |
| bezel Ouverture | 110.6(W)×46.0(H) mm |
| Kontur Gréisst | 120.7(W)×56.16(H) ×3.3(D) mm |
| Uewerfläch | - |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) (TM) |
| Vue Wénkel | 65/65/55/65 (Typ.)(CR≥10) |
| Display Modus | TN, Normally White, Transmissive |
| beschte Vue op | 12 o'clock |
| Äntwert Zäit | 20 (Typ.)(Tr+Td) |
| weisen Faarwen | 16.7M 50% NTSC |
| Lampe Typ | 6S2P WLED , 25K hours , Without Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | TBD |
| Applikatioun | Industrial |
| Signal Interface | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| Input Volt | 3.3V (Typ.)(VDD) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
