| Part Number | S039WQ01 |
| Mark | CDTECH |
| Gréisst | 3.9 |
| Applikatioun | Industrial Stretched |
| Opléisung | 480×128 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | 5S2P WLED , 30K hours , No Driver |
| Interface | |
| Fabrikant beschwéiert | CDTECH |
| Modell Numm | S039WQ01 |
| Écran Gréisst | 3.9 inch (1/2 cut of 4.3") |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 480(RGB)×128 128PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 95.04 × 25.34 (H×V) |
| Kontur (mm) | 105.5 × 40.64 × 3.15 (H×V×D) |
| Bezel Beräich (mm) | 98.04 × 28.34 (H×V) |
| Behandlung | - |
| luminance | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 500 : 1 (Typ.) (TM) |
| Vue Wénkel | 65/65/55/65 (Typ.)(CR≥10) |
| Äntwert | 10/15 (Typ.)(Tr/Td) ms |
| gutt Vue op | 12 o'clock |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 16.7M 50% NTSC |
| mass | TBD |
| benotzt fir | Industrial Stretched Bar LCD Automotive Display |
| Erfrëschungsrate | - |
| touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
