| Part Number | RGS31256032WH000 |
| Mark | RiTdisplay |
| Gréisst | 3.1 |
| Applikatioun | IA |
| Opléisung | 256×32 |
| Zesummesetzung | OLED |
| Hellegkeet | 100 |
| CR | 2000:1 |
| Faarwen | Mono(White) |
| Géigeliicht | self |
| Interface | CPU/SPI/I²C |
| Panel Mark | RiTdisplay |
| Panel Modell | RGS31256032WH000 |
| Panel Typ | PM-OLED , OLED |
| Panel Gréisst | 3.1 inch |
| Resolutioun | 256×32 |
| aktiv Beräich | 79.084×9.868 mm |
| skizzéieren | 83.8×18×1.71 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 100 cd/m² (Typ.) |
| Kontrast Verhältnis | 2000 : 1 (Min.) |
| weisen Faarwen | Mono(White) (1-bit) |
| Vue Wénkel | 80/80/80/80 (Min.)(L/R/U/D) |
| Frequenz | 105Hz |
| Chauffeur ic | COF Built-in SSD1326U3R1 |
| Signal Interface | 8-bit 6800/8080 parallel, SPI, I²C, 25 pins |
| Input Volt | 12/2.7V (Typ.)(VCC/VDD) |
| Applikatioun | IA |
| AMFN888 | Samsung | 3.1 | 480×800 |
| EL160.120.39 | Lumineq | 3.1 | 160×120 |
| EL160.120.39 CC | Lumineq | 3.1 | 160×120 |
| LT031MDZ4000 | JDI | 3.1 | 720×720 |
| RGS31256032WH000 | RiTdisplay | 3.1 | 256×32 |
| UG-5664ALBEF01 | WiseChip | 3.1 | 256×64 |
| UG-5664ASGEF01 | WiseChip | 3.1 | 256×64 |
| UG-5664ASWEF01 | WiseChip | 3.1 | 256×64 |
| UG-5664ASYEF01 | WiseChip | 3.1 | 256×64 |
| AA104VH01 | Mitsubishi | 10.4 | 640×480 |
| EL320.240.36 AG | Lumineq | 5.7 | 320×240 |
| F-51430NFU-FW-AA | Kyocera | 9.4 | 640×480 |
| G057AGE-T01 | Innolux | 5.7 | 320×240 |
| G057VN01 V2 | AUO | 5.7 | 640×480 |
| KCS057QV1AJ-G23 | Kyocera | 5.7 | 320×240 |
| LM084SS1T01 | SHARP | 8.4 | 800×600 |
| LQ121S1DG61 | SHARP | 12.1 | 800×600 |
| RGS10096064WR001 | RiTdisplay | 0.95 | 96×64 |
| TM080VG-22L01 | SANYO | 8.0 | 640×480 |
