| Part Number | QV116FHB-N81 |
| Mark | BOE |
| Gréisst | 11.6 |
| Applikatioun | Industrial |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | No |
| Interface | eDP |
| Mark | BOE |
| Modell | QV116FHB-N81 |
| diagonal Gréisst | 11.6 inch |
| Typ | a-Si TFT-LCD, CELL |
| Pixel Format | 1920(RGB)×1080 [FHD] 190PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 256.32(H)×144.18(V) mm |
| kontur dim. | 260.32(H)×152.08(V) ×1.06(D) mm |
| bezel Beräich | - |
| Behandlung | Antiglare (Haze 25%), Hard coating (3H) |
| luminance | 0 cd/m² |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Betribssystemer Modus | ADS, Normally Black, Transmissive |
| Plackedicke | 0.50+0.50 mm |
| Iwwerdroung | - |
| Ënnerstëtzung Faarf | 16.7M |
| Liichtquell | No B/L |
| Gewiicht | TBD |
| entworf fir | Industrial |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| d-ic detail | COG Built-in 4 source chips |
| Interface Typ | eDP (2 Lanes) , 30 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| B116HAN03.1 | AUO | 11.6 | 1920×1080 |
| B116XW02 V1 | AUO | 11.6 | 1366×768 |
| LP116WH1-TLP1 | LG Display | 11.6 | 1366×768 |
| LP116WH4-TJA3 | LG Display | 11.6 | 1366×768 |
| LP116WH6-SPA2 | LG Display | 11.6 | 1366×768 |
| LTN116AT01-801 | Samsung | 11.6 | 1366×768 |
| LTN116AT07-B01 | Samsung | 11.6 | 1366×768 |
| N116BGE-L32 | Innolux | 11.6 | 1366×768 |
| VVX11F009G00 | Panasonic | 11.6 | 1920×1080 |
| VVX11F019G00 | Panasonic | 11.6 | 1920×1080 |
