| Part Number | PV190E0M-N10 |
| Mark | BOE |
| Gréisst | 19.0 |
| Applikatioun | Industrial |
| Opléisung | 1280×1024 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED , 50K hours , No Driver |
| Interface | |
| Fabrikant beschwéiert | BOE |
| Écran Gréisst | 19.0 inch |
| Pixel Zuel | 1280(RGB)×1024 (SXGA) 86PPI |
| aktiv Beräich (mm) | 374.784 × 299.827 (H×V) |
| Bezel Beräich (mm) | 379 × 303 (H×V) |
| luminance | 400 (Typ.)(cd/m²) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 16.7M 73% NTSC |
| mass | 1.95Kgs (Typ.) |
| Erfrëschungsrate | 60Hz |
| Modell Numm | PV190E0M-N10 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 396 × 324 × 12.13 (H×V×D) |
| Behandlung | Antiglare (Haze 25%), Hard coating (3H) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Aarbecht Modus | ADS, Normally Black, Transmissive |
| Äntwert | 14 (Typ.)(G to G) ms |
| benotzt fir | Industrial |
| touchscreen | Without |
