| Part Number | PJ050IA-05L |
| Mark | Innolux |
| Gréisst | 5.0 |
| Applikatioun | Mobile Phone |
| Opléisung | 720×1280 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 6S2P WLED , No Driver |
| Interface | MIPI |
| Fabrikant beschwéiert | Innolux |
| Modell Numm | PJ050IA-05L |
| Écran Gréisst | 5.0 inch |
| Écran Typ | LCM , a-Si TFT-LCD |
| Pixel Zuel | 720(RGB)×1280 (WXGA) 294PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 62.1 × 110.4 (H×V) |
| Kontur (mm) | 64.18 × 117.56 × 1.42 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Glare (Haze 0%), Hard coating (3H) |
| luminance | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Äntwert | 25 (Typ.)(Tr+Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | AAS, Normally Black, Transmissive |
| Faarfdéift | 16.7M 72% NTSC |
| mass | 17.2g |
| benotzt fir | Mobile Phone |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | MIPI (4 data lanes) , 30 pins Connector |
| Spannungsversuergung | 1.8/5.4/-5.4V (Typ.)(VDDI/AVDD/AVEE) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
