| Part Number | PD035VX2 |
| Mark | E Ink |
| Gréisst | 3.5 |
| Applikatioun | PND |
| Opléisung | 640×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 450 |
| CR | 600:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | PVI |
| Panel Modell | PD035VX2 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 3.5 inch |
| Resolutioun | 640(RGB)×480 , VGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 72×52.56 mm |
| skizzéieren | 84.03×65.24 mm |
| Uewerfläch | Antiglare |
| Hellegkeet | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 600:1 (Typ.) |
| weisen Faarwen | 262K (6-bit) |
| Äntwert Zäit | 15/25 (Typ.)(Tr/Td) |
| Vue Wénkel | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 3S2PWLEDWithout Driver |
| Signal Interface | TTL (1 ch, 6-bit), 50 pins |
| Input Volt | 3.3/3.3/10/17/-10V (Typ.)(VCC/VDD/VDD1/VCG/VEE) |
| Applikatioun | PND |
