| Part Number | P320HVN03.1 |
| Mark | AUO |
| Gréisst | 32.0 |
| Applikatioun | Digital Signage Outd |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 3000:1 |
| Faarwen | 1.07B |
| Géigeliicht | WLED , 60K hours , With LED Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | AUO |
| Modell Numm | P320HVN03.1 |
| Écran Gréisst | 32.0 inch |
| Écran Typ | LCM , a-Si TFT-LCD |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 69PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 698.4 × 392.85 (H×V) |
| Kontur (mm) | 719.2 × 413.7 × 28.6 (H×V×D) |
| Bezel Beräich (mm) | 703.4 × 397.9 (H×V) |
| Behandlung | Hard coating, Antireflection |
| luminance | 1000 cd/m² (Typ.) |
| Kontrast Verhältnis | 3000 : 1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Äntwert | 8 (Typ.)(G to G) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | AMVA3, Normally Black, Transmissive |
| Faarfdéift | 1.07B 99% sRGB |
| mass | 4.92Kgs (Typ.) |
| benotzt fir | Digital Signage Outdoor High Brightness |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | LVDS (2 ch, 10-bit) , 51 pins Connector |
| Spannungsversuergung | 12.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| BRS-320H02 | 32.0 | 1920×1080 | |
| M320QAN01.0 | AUO | 32.0 | 3840×2160 |
| P320HVN01.0 | AUO | 31.5 | 1920×1080 |
| P320HVN01.1 | AUO | 31.5 | 1920×1080 |
| P320HVN02.0 | AUO | 31.5 | 1920×1080 |
| P320HVN02.1 | AUO | 31.5 | 1920×1080 |
| V320B1-L01 | Innolux | 32.0 | 1366×768 |
| V320B1-L06 | Innolux | 32.0 | 1366×768 |
