| Part Number | NV140QUM-N51 |
| Mark | BOE |
| Gréisst | 14.0 |
| Applikatioun | Laptop |
| Opléisung | 3840×2160 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | 10S6P |
| Interface | eDP |
| Panel Mark | BOE |
| Panel Modell | NV140QUM-N51 (BOE06DE) |
| Panel Gréisst | 14.0" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 3840(RGB)×2160, UHD, 315PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 309.31(W)×173.99(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 315.01(W)×194.66(H) ×2.4(D) mm |
| Uewerfläch | - |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Display Modus | ADS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 35 (Max.)(Tr+Td) |
| weisen Faarwen | 16.7M 100% sRGB |
| Lampe Typ | 10S6P WLED , 15K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Form Stil | Slim (PCBA Flat, T≤3.2mm) |
| Applikatioun | Laptop |
| Signal Interface | eDP (4 Lanes) , HBR2 (5.4G/lane) , 40 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -20 ~ 65 °C |
| B140HAT02.0 | AUO | 14.0 | 1920×1080 |
| BT140GW02 V.9 | Innolux | 14.0 | 1366×768 |
| HSD140PHW2-A00 | HannStar | 14.0 | 1366×768 |
| HT140WXB-601 | BOE | 14.0 | 1366×768 |
| LP140WH6-TLB1 | LG Display | 14.0 | 1366×768 |
| LTN140AT07-306 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-801 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-802 | Samsung | 14.0 | 1366×768 |
| N140BGE-L11 | Innolux | 14.0 | 1366×768 |
| NV140FHM-N41 | BOE | 14.0 | 1920×1080 |
