| Part Number | NV140FHM-N32 |
| Mark | BOE |
| Gréisst | 14.0 |
| Applikatioun | Laptop |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 262K |
| Géigeliicht | 10S4P |
| Interface | |
| Panel Mark | BOE |
| Panel Gréisst | 14.0" |
| Resolutioun | 1920(RGB)×1080, FHD, 157PPI |
| Affichage Beräich | 309.31(W)×173.99(H) mm |
| Kontur Gréisst | 320.4(W)×198.6(H) ×3(D) mm |
| Hellegkeet | 250 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 262K |
| Frequenz | 60Hz |
| Form Stil | Slim (PCBA Flat, T≤3.2mm) |
| Panel Modell | NV140FHM-N32 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Glare (Haze 0%), Hard coating (3H) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Display Modus | ADS, Normally Black, Transmissive |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Lampe Typ | 10S4P WLED , 15K hours , With LED Driver |
| Touchscreens | Without |
| Applikatioun | Laptop |
