| Part Number | NV125QUM-N81 |
| Mark | BOE |
| Gréisst | 12.5 |
| Applikatioun | NBPC |
| Opléisung | 3840×2160 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 1500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | BOE |
| Panel Modell | NV125QUM-N81 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 12.5 inch |
| Resolutioun | 3840(RGB)×2160 , UHD |
| Display Modus | HADS, Normally Black, Transmissive |
| aktiv Beräich | 276.48×155.52 mm |
| skizzéieren | 282.08×168.89×4.6 mm |
| Form Stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| Uewerfläch | Antiglare |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 1500:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), Adobe100% |
| Äntwert Zäit | 35 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 8S8PWLEDEmbedded (LED Driver) |
| Signal Interface | eDP (4 Lanes), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
