| Part Number | NE133FHM-N57 |
| Mark | BOE |
| Gréisst | 13.3 |
| Applikatioun | Laptop |
| Opléisung | 1920×1080 |
| Zesummesetzung | Oxide TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 10S6P |
| Interface | eDP |
| Panel Mark | BOE |
| Panel Gréisst | 13.3" |
| Resolutioun | 1920(RGB)×1080, FHD, 166PPI |
| Affichage Beräich | 293.76(W)×165.24(H) mm |
| Kontur Gréisst | 298.76(W)×181.33(H) ×2.44(D) mm |
| Hellegkeet | 400 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 100% DCI-P3 |
| Frequenz | 60Hz |
| Form Stil | Slim (PCBA Flat, T≤3.2mm) |
| Signal Interface | eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 30 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 70 °C |
| Panel Modell | NE133FHM-N57 (BOE087A) |
| Panel Typ | Oxide TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | - |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Display Modus | FFS, Normally Black, Transmissive |
| Äntwert Zäit | 25 (Typ.)(Tr+Td); 25 (Typ.)(G to G) |
| Lampe Typ | 10S6P QLED , 15K hours , Without Driver |
| Touchscreens | Without |
| Applikatioun | Laptop |
