| Part Number | NE133FHM-N56 |
| Mark | BOE |
| Gréisst | 13.3 |
| Applikatioun | Laptop |
| Opléisung | 1920×1080 |
| Zesummesetzung | Oxide TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Mark | BOE |
| Modell | NE133FHM-N56 (BOE088C) |
| diagonal Gréisst | 13.3 inch |
| Typ | Oxide TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×1080 [FHD] 166PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 293.76(H)×165.24(V) mm |
| kontur dim. | 298.76(H)×176.24(V) ×4.1(D) mm |
| bezel Beräich | - |
| Behandlung | Antiglare (Haze 25%), Hard coating (3H) |
| luminance | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Betribssystemer Modus | ADS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M |
| Liichtquell | WLED [11S4P] , 15K hours , W/O Driver |
| Form Stil | Slim (PCBA Bent, T≤3.0mm) |
| entworf fir | Laptop |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 30 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 70 °C |
| B133XTN01.6 HW1A | AUO | 13.3 | 1366×768 |
| CLAA133WA01A | CPT | 13.3 | 1366×768 |
| LP133WD1-SLA1 | LG Display | 13.3 | 1600×900 |
| LP133WH2-SPA2 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLM2 | LG Display | 13.3 | 1366×768 |
| LQ133K1LA04 | SHARP | 13.3 | 1280×800 |
| LQ13X32 | SHARP | 13.3 | 1024×768 |
| LTN133AT01-003 | Samsung | 13.3 | 1280×800 |
| LTN133AT05-001 | Samsung | 13.3 | 1280×800 |
| M133NWN1 R3 | IVO | 13.3 | 1366×768 |
