| Part Number | N140JCN-GS9 |
| Mark | Innolux |
| Gréisst | 14.0 |
| Applikatioun | Laptop |
| Opléisung | 1920×1200 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Mark | Innolux |
| Modell | N140JCN-GS9 (CMN1417) |
| diagonal Gréisst | 14.0 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×1200 [WUXGA] 161PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 301.594(H)×188.496(V) mm |
| kontur dim. | 306.59(H)×198.6(V) ×4.5(D) mm |
| bezel Beräich | - |
| Behandlung | Antiglare, Hard coating (3H) |
| luminance | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 1500:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 16/14 (Typ.)(Tr/Tf) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Betribssystemer Modus | AAS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 100% sRGB |
| Liichtquell | WLED , 15K hours , With LED Driver |
| Form Stil | Slim (PCBA Bent, T≤3.0mm) |
| entworf fir | Laptop |
| Frame Taux | 60Hz |
| Touch Panel | On-Cell Touch |
| Interface Typ | eDP (2 Lanes) , eDP1.4 , 40 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
