| Part Number | N080JCE-G41 Rev.A1 |
| Mark | Innolux |
| Gréisst | 8.0 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1200×1920 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Panel Mark | Innolux |
| Panel Modell | N080JCE-G41 Rev.A1 |
| Panel Gréisst | 8.0" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1200(RGB)×1920, WUXGA, 283PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 107.64(W)×172.224(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 114.6(W)×184.6(H) ×3.65(D) mm |
| Uewerfläch | Glare (Haze 0%), Hard coating (3H) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | AAS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| weisen Faarwen | 16.7M 60% NTSC |
| Lampe Typ | WLED , 15K hours , Without Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 80.0g (Max.) |
| Applikatioun | Pad & Tablet |
| Signal Interface | MIPI (4 data lanes) , 45 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -20 ~ 70 °C |
| A080SN01 V5 | AUO | 8.0 | 800×600 |
| BP080WX1-100 | BOE | 8.0 | 1280×800 |
| EJ080NA-04A | Innolux | 8.0 | 1024×768 |
| HJ080IA-01E | Innolux | 8.0 | 1024×768 |
| LB080WV3-A3 | LG Display | 8.0 | 800×480 |
| LQ080T3AG01 | SHARP | 8.0 | 480×234 |
| LQ080Y5DG03 | SHARP | 8.0 | 800×480 |
| LQ080Y5DR01 | SHARP | 8.0 | 800×480 |
| N080JCE-G41 | Innolux | 8.0 | 1200×1920 |
| TV080X0M-NS0 | BOE | 8.0 | 768×1024 |
