| Part Number | MV238QHB-N10 |
| Mark | BOE |
| Gréisst | 23.8 |
| Applikatioun | Desktop Monitor |
| Opléisung | 2560×1440 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | No |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Modell | MV238QHB-N10 |
| Panel Gréisst | 23.8" |
| Panel Typ | a-Si TFT-LCD, CELL |
| Resolutioun | 2560(RGB)×1440, Quad-HD, 123PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 526.848(W)×296.352(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 534.84(W)×308.16(H) ×1.32(D) mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 0 cd/m² |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | ADS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 14 (Typ.)(G to G) |
| Glas Déift | 0.50+0.50 mm |
| transmissivitéit | - |
| weisen Faarwen | 16.7M 100% sRGB |
| Lampe Typ | No B/L |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Chauffeur ic | COF Built-in 8 source chips |
| Panel Gewiicht | TBD |
| Applikatioun | Desktop Monitor |
| Signal Interface | LVDS (4 ch, 8-bit) , 70 pins Connector |
| Input Volt | 5.0V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
