| Part Number | MV238FHM-N60 |
| Mark | BOE |
| Gréisst | 23.8 |
| Applikatioun | Desktop Monitor |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 20S4P |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Gréisst | 23.8" |
| Resolutioun | 1920(RGB)×1080, FHD, 92PPI |
| Affichage Beräich | 527.04(W)×296.46(H) mm |
| Kontur Gréisst | 535(W)×313(H) ×12.5(D) mm |
| Hellegkeet | 250 cd/m² (Typ.) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 72% NTSC |
| Frequenz | 60Hz |
| Panel Gewiicht | 2.20Kgs (Typ.) |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Volt | 5.0V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Modell | MV238FHM-N60 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Display Modus | ADS, Normally Black, Transmissive |
| Äntwert Zäit | 14 (Typ.)(G to G) |
| Lampe Typ | 20S4P WLED , 30K hours , Without Driver |
| Touchscreens | Without |
| Applikatioun | Desktop Monitor |
