| Part Number | MNE007ZA1-1 |
| Mark | CSOT |
| Gréisst | 14.0 |
| Applikatioun | Laptop |
| Opléisung | 2880×1800 |
| Zesummesetzung | LTPS TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 1.07B |
| Géigeliicht | 10S6P |
| Interface | eDP |
| Panel Mark | CSOT |
| Panel Modell | MNE007ZA1-1 |
| Panel Gréisst | 14.0" |
| Panel Typ | LTPS TFT-LCD, LCM |
| Resolutioun | 2880(RGB)×1800, 242PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 301.536(W)×188.46(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 306.54(W)×204.46(H) ×2.4(D) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 1500:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | FFS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 20 (Typ.)(Tr+Td) |
| weisen Faarwen | 1.07B 100% sRGB |
| Lampe Typ | 10S6P WLED , 15K hours , With LED Driver |
| Frequenz | 90Hz |
| Touchscreens | Without |
| Form Stil | Slim (PCBA Flat, T≤3.2mm) |
| Applikatioun | Laptop |
| Signal Interface | eDP (4 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 40 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B140XW03 V1 | AUO | 14.0 | 1366×768 |
| HB140WX1-100 | BOE | 14.0 | 1366×768 |
| LP140WH1-TLE3 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLE2 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLEA | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLM1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLM2 | LG Display | 14.0 | 1366×768 |
| LTN140AT01-G01 | Samsung | 14.0 | 1366×768 |
| M140NWR2 R1 | IVO | 14.0 | 1366×768 |
| N140FGE-EA2 | Innolux | 14.0 | 1600×900 |
