| Part Number | MCG156FDLAAQNN-AN20 |
| Mark | Kyocera |
| Gréisst | 15.6 |
| Applikatioun | Industrial |
| Opléisung | 1920×1080 |
| Zesummesetzung | LTPS TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.2M |
| Géigeliicht | WLED |
| Interface | |
| Panel Mark | Kyocera |
| Panel Gréisst | 15.6" |
| Resolutioun | 1920(RGB)×1080, FHD, 141PPI |
| Affichage Beräich | 344.16(W)×193.59(H) mm |
| Kontur Gréisst | 363.8(W)×215.9(H) ×9.8(D) mm |
| Hellegkeet | 450 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.2M 73% NTSC |
| Frequenz | 60Hz |
| Gewiicht | 1.05/1.09Kgs (Typ./Max.) |
| Panel Modell | MCG156FDLAAQNN-AN20 |
| Panel Typ | LTPS TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | 347.06(W)×196.49(H) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Display Modus | AWV, Normally Black, Transmissive |
| Äntwert Zäit | 13/12 (Typ.)(Tr/Td) |
| Lampe Typ | WLED , 50K hours , With LED Driver |
| Touchscreens | Without |
| Applikatioun | Industrial |
