| Part Number | M238DAN01.1Q0 |
| Mark | AUO |
| Gréisst | 23.8 |
| Applikatioun | Desktop Monitor |
| Opléisung | 2560×1440 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 20S4P |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | M238DAN01.1Q0 |
| Panel Gréisst | 23.8" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 2560(RGB)×1440, Quad-HD, 123PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 526.85(W)×296.35(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 534.74(W)×313.26(H) ×12.3(D) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | AHVA, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 14 (Typ.)(G to G) |
| weisen Faarwen | 16.7M 100% sRGB |
| Lampe Typ | 20S4P WLED , 30K hours , Without Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 2.20Kgs (Typ.) |
| Applikatioun | Desktop Monitor |
| Signal Interface | LVDS (4 ch, 8-bit) , 92 pins Connector |
| Input Volt | 5.0V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
