| Part Number | M230HCJ-L3N Rev.C1 |
| Mark | Innolux |
| Gréisst | 23.0 |
| Applikatioun | Desktop Monitor |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 4 |
| Interface | LVDS |
| Panel Mark | Innolux |
| Panel Modell | M230HCJ-L3N Rev.C1 |
| Panel Gréisst | 23.0" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1920(RGB)×1080, FHD, 95PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 509.184(W)×286.416(H) mm |
| bezel Ouverture | 512.38(W)×289.62(H) mm |
| Kontur Gréisst | 522.38(W)×305.62(H) mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | AAS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 8/7 (Typ.)(Tr/Td) |
| weisen Faarwen | 16.7M 72% NTSC |
| Lampe Typ | 4 strings WLED , Without Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 1.96/2.06/2.23Kgs (Min./Typ./Max.) |
| Applikatioun | Desktop Monitor |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Volt | 5.0V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
