| Part Number | M090AWP4 R0 |
| Mark | IVO |
| Gréisst | 9.0 |
| Applikatioun | Outdoor High Brightn |
| Opléisung | 800×480 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 700:1 |
| Faarwen | 262K |
| Géigeliicht | 8S3P |
| Interface | Parallel |
| Panel Mark | IVO |
| Panel Gréisst | 9.0" |
| Resolutioun | 800(RGB)×480, WVGA, 104PPI |
| Affichage Beräich | 198(W)×112.08(H) mm |
| Kontur Gréisst | 210.82(W)×126.96(H) ×6.4(D) mm |
| Hellegkeet | 750 cd/m² (Typ.) |
| Vue Wénkel | 70/70/50/70 (Typ.)(CR≥10) |
| beschte Vue op | 6 o'clock |
| weisen Faarwen | 262K 70% NTSC |
| Frequenz | 60Hz |
| Panel Gewiicht | 251g (Max.) |
| Signal Interface | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| Input Volt | 3.3/11.6/22/-7V (Typ.)(VCC/VDDA/VGH/VGL) |
| Ëmwelt | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| Panel Modell | M090AWP4 R0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | 200.2(W)×114.28(H) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 700:1 (Typ.) (TM) |
| Display Modus | TN, Normally White, Transmissive |
| Äntwert Zäit | 12 (Typ.)(Tr+Td) |
| Lampe Typ | 8S3P WLED , 30K hours , Without Driver |
| Touchscreens | Without |
| Applikatioun | Outdoor High Brightness Automotive Display |
