| Part Number | M070SWP1 R5 |
| Mark | IVO |
| Gréisst | 7.0 |
| Applikatioun | IA |
| Opléisung | 800×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 350 |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | IVO |
| Panel Modell | M070SWP1 R5 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 7.0 inch |
| Resolutioun | 800(RGB)×480 , WVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 153.6×86.64 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 500:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193150% |
| Äntwert Zäit | 16 (Typ.)(Tr+Td) |
| Vue Wénkel | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLED |
| Signal Interface | TTL (1 ch, 8-bit) |
| Applikatioun | IA |
| BP070WX1-300 | BOE | 7.0 | 800×1280 |
| CLAA069LA0FCW | CPT | 7.0 | 800×480 |
| CLAA070WP06G XG | CPT | 7.0 | 800×1280 |
| DLC0700YZG-1 | Other | 7.0 | 1024×600 |
| LB070W02-TMJ2 | LG Display | 7.0 | 480×234 |
| LQ070Y3LG05 | SHARP | 7.0 | 800×480 |
| M070SW46 R0 | IVO | 7.0 | 1200×1920 |
| M070SWP1 R4 | IVO | 7.0 | 800×480 |
| M070SWP1 R5 | IVO | 7.0 | 800×480 |
| TM070DDH07 | Tianma | 7.0 | 1024×600 |
| AA104SH02--T1 | Mitsubishi | 10.4 | 800×600 |
| G101STN01.3 | AUO | 10.1 | 1024×600 |
| G104S1-L01 | Innolux | 10.4 | 800×600 |
| G150XTN06.0 | AUO | 15.0 | 1024×768 |
| LQ121S1DG61 | SHARP | 12.1 | 800×600 |
| LS037V3DX01 | SHARP | 3.7 | 640×480 |
| LTA084C190F | TOSHIBA | 8.4 | 800×600 |
| LTD104C11Z | TOSHIBA | 10.4 | 640×480 |
| NL10276AC20-03 | NLT | 10.4 | 1024×768 |
| UG-5664ASWEF01 | WiseChip | 3.1 | 256×64 |
