| Part Number | LTY400HF06 |
| Mark | Samsung |
| Gréisst | 40 |
| Applikatioun | LCTV |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 5000:1 |
| Faarwen | 1.07B |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | SAMSUNG |
| Panel Modell | LTY400HF06 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 40 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | S-PVA, Normally Black, Transmissive |
| aktiv Beräich | 885.6×498.15 mm |
| skizzéieren | 952×551×61.2 mm |
| Uewerfläch | Antiglare (Haze 4.5%), Hard coating (3H) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 5000:1 (Typ.) |
| weisen Faarwen | 1.07B (8-bit + Hi-FRC), CIE193172% |
| Äntwert Zäit | 12/6 (Typ.)(Tr/Td); 6.5 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Lampe Typ | 10 pcsCCFLEmbedded (Inverter) |
| Signal Interface | LVDS (2 ch, 10-bit), 55 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | LCTV |
