| Part Number | LTM201M1-L01 |
| Mark | Samsung |
| Gréisst | 20.1 |
| Applikatioun | DMPC |
| Opléisung | 1680×1050 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | SAMSUNG |
| Panel Modell | LTM201M1-L01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 20.1 inch |
| Resolutioun | 1680(RGB)×1050 , WSXGA+ |
| Display Modus | S-PVA, Normally Black, Transmissive |
| aktiv Beräich | 433.44×270.9 mm |
| skizzéieren | 459.4×296.4 mm |
| Uewerfläch | Antiglare (Haze 44%), Hard coating (3H) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 900:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 16 (Typ.)(Tr+Td); 8 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 6 pcsCCFLWithout Driver |
| Signal Interface | LVDS (2 ch, 8-bit), 30 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | DMPC |
| IAWS64 | IDTech | 20.1 | 1680×1050 |
| LM201U04-A3KC | LG Display | 20.1 | 1600×1200 |
| LM201U05-SLA3 | LG Display | 20.1 | 1600×1200 |
| LM201WE3-TLE1 | LG Display | 20.1 | 1680×1050 |
| LM201WE3-TLF8 | LG Display | 20.1 | 1680×1050 |
| LQ201U1LW31 | SHARP | 20.1 | 1600×1200 |
| LTM201M1-L01 | Samsung | 20.1 | 1680×1050 |
| LTM201M2-L02 | Samsung | 20.1 | 1680×1050 |
| LTM201U1-L01 | Samsung | 20.1 | 1600×1200 |
| V201B1-L01 | Innolux | 20.1 | 1366×768 |
| CLAA150XP01Q V2 | CPT | 15.0 | 1024×768 |
| LM171WX3-TLA1 | LG Display | 17.1 | 1440×900 |
| LM185WH1-TLF4 | LG Display | 18.5 | 1366×768 |
| LM190E02-A4 | LG Display | 19.0 | 1280×1024 |
| LM270WF5-SSC1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SLC1 | LG Display | 27.0 | 2560×1440 |
| LTM190EX-L01 | Samsung | 19.0 | 1280×1024 |
| LTM200KT01 | Samsung | 20.0 | 1600×900 |
| M185BGE-L23 | Innolux | 18.5 | 1366×768 |
| M270HTN01.0 | AUO | 27.0 | 1920×1080 |
