| Part Number | LSM490YP01 |
| Mark | SAMSUNG |
| Gréisst | 49 |
| Applikatioun | Desktop Monitor |
| Opléisung | 3840×1080 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 3000:1 |
| Faarwen | 1.07B |
| Géigeliicht | No |
| Interface | eDP |
| Panel Mark | SAMSUNG |
| Panel Modell | LSM490YP01 |
| Panel Gréisst | 49" |
| Panel Typ | a-Si TFT-LCD, CELL |
| Resolutioun | 3840(RGB)×1080, 81PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 1195.78(W)×336.31(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 1208.18(W)×350.012(H) ×1.11(D) mm |
| Uewerfläch | Antiglare (Haze 25%) |
| Hellegkeet | 0 cd/m² |
| Kontrast Verhältnis | 3000:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | SVA, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 8 (Typ.)(G to G |
| Glas Déift | 0.40+0.40 mm |
| transmissivitéit | 4.1% (Typ.)(with Polarizer) |
| weisen Faarwen | 1.07B |
| Lampe Typ | No B/L |
| Frequenz | 144Hz |
| Touchscreens | - |
| Chauffeur ic | COF Built-in 12 source chips |
| Panel Gewiicht | 1.30Kgs (Max.) |
| Applikatioun | Desktop Monitor |
| Signal Interface | eDP (8 Lanes) , HBR1 (2.7G/lane) , 51 pins Connector |
| Input Volt | 12.0V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
