| Part Number | LSM315DP01-M01 |
| Mark | SAMSUNG |
| Gréisst | 32.0 |
| Applikatioun | Desktop Monitor Gami |
| Opléisung | 2560×1440 |
| Zesummesetzung | a-Si TFT-LCD , CELL |
| Hellegkeet | |
| CR | 3000:1 |
| Faarwen | 16.7M |
| Géigeliicht | No |
| Interface | eDP |
| Mark | SAMSUNG |
| diagonal Gréisst | 32.0 inch |
| Pixel Format | 2560(RGB)×1440 [Quad-HD] 93PPI |
| aktiv Beräich | 697.344(H)×392.256(V) mm |
| bezel Beräich | - |
| luminance | 0 cd/m² |
| Vue Richtung | Symmetry |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Plackedicke | 0.40+0.40 mm |
| Ënnerstëtzung Faarf | 16.7M 70% NTSC |
| Gewiicht | 900g (Typ.) |
| Frame Taux | 144Hz |
| d-ic detail | COF Built-in 8 source chips |
| Interface Typ | eDP (4 Lanes) , HBR2 (5.4G/lane) , 51 pins Connector |
| Stroumversuergung | 12.0V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| Modell | LSM315DP01-M01 |
| Typ | a-Si TFT-LCD , CELL |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 708.944(H)×405.731(V) ×1.11(D) mm |
| Behandlung | Antiglare (Haze 25%) |
| Kontrast Verhältnis | 3000:1 (Typ.) (TM) |
| Äntwert Zäit | 22 (Typ.)(G to G) |
| Betribssystemer Modus | PVA, Normally Black, Transmissive |
| Iwwerdroung | 3.0% (Typ.)(with Polarizer) |
| Liichtquell | No B/L |
| entworf fir | Desktop Monitor Gaming |
| Touch Panel | Without |
