| Part Number | LSC550HN06-W |
| Mark | SAMSUNG |
| Gréisst | 55 |
| Applikatioun | TV Sets |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD , CELL |
| Hellegkeet | |
| CR | 5000:1 |
| Faarwen | 1.07B |
| Géigeliicht | No |
| Interface | LVDS |
| Mark | SAMSUNG |
| diagonal Gréisst | 55 inch |
| Pixel Format | 1920(RGB)×1080 [FHD] 40PPI |
| aktiv Beräich | 1209.6(H)×680.4(V) mm |
| bezel Beräich | - |
| luminance | 0 cd/m² |
| Vue Richtung | Symmetry |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Plackedicke | 0.40+0.50 mm |
| Ënnerstëtzung Faarf | 1.07B 99% sRGB |
| Gewiicht | 2.33Kgs (Typ.) |
| Frame Taux | 60Hz |
| d-ic detail | COF Built-in 6 source chips |
| Interface Typ | LVDS (2 ch, 10-bit) , 51 pins Connector |
| Stroumversuergung | 12.0V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
| Modell | LSC550HN06-W |
| Typ | a-Si TFT-LCD , CELL |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 1219.6(H)×692.9(V) ×1.3(D) mm |
| Behandlung | Antiglare (Haze 2.3%), Hard coating (2H) |
| Kontrast Verhältnis | 5000:1 (Typ.) (TM) |
| Äntwert Zäit | 6 (Typ.)(G to G) |
| Betribssystemer Modus | SVA, Normally Black, Transmissive |
| Iwwerdroung | 7.0% (Typ.)(with Polarizer) |
| Liichtquell | No B/L |
| entworf fir | TV Sets |
| Touch Panel | Without |
