| Part Number | LSC480HN08-W |
| Mark | SAMSUNG |
| Gréisst | 48 |
| Applikatioun | TV Sets |
| Opléisung | 1920×1080 |
| Zesummesetzung | CELL, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 5000:1 |
| Faarwen | 1.07B |
| Géigeliicht | No B/L |
| Interface | LVDS |
| Fabrikant beschwéiert | SAMSUNG |
| Modell Numm | LSC480HN08-W |
| Écran Gréisst | 48 inch |
| Écran Typ | CELL, a-Si TFT-LCD |
| Pixel Zuel | 1920×1080(RGB) (FHD) 46PPI |
| Arrangement | RGB Horizontal Stripe |
| aktiv Beräich (mm) | 1054.08 × 592.92 (H×V) |
| Kontur (mm) | 1068.08 × 608.92 × 1.4 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Antiglare (Haze 2.3%), Hard coating (2H) |
| luminance | 0 cd/m² |
| Kontrast Verhältnis | 5000 : 1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Äntwert | 8 (Typ.)(G to G) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | SVA, Normally Black, Transmissive |
| Glas deck | 0.50+0.50 mm |
| transmissivitéit | 6.6% (Typ.)(with Polarizer) |
| Faarfdéift | 1.07B 68% NTSC |
| mass | 1.90Kgs (Typ.) |
| benotzt fir | TV Sets |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Chauffer ic Lëscht | Built-in COF 3 source chips |
| Signal Typ | LVDS (2 ch, 10-bit) , Connector 51 pins |
| Spannungsversuergung | 12.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C |
