| Part Number | LSC320AN09-H |
| Mark | SAMSUNG |
| Gréisst | 32.0 |
| Applikatioun | TV Sets |
| Opléisung | 1366×768 |
| Zesummesetzung | a-Si TFT-LCD , CELL |
| Hellegkeet | |
| CR | 4000:1 |
| Faarwen | 16.7M |
| Géigeliicht | No |
| Interface | LVDS |
| Panel Mark | SAMSUNG |
| Panel Gréisst | 32.0" |
| Resolutioun | 1366×768(RGB), WXGA, 49PPI |
| Affichage Beräich | 697.685(W)×392.256(H) mm |
| Kontur Gréisst | 713(W)×410.5(H) ×1.3(D) mm |
| Hellegkeet | 0 cd/m² |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| Glas Déift | 0.50+0.50 mm |
| weisen Faarwen | 16.7M 69% NTSC |
| Frequenz | 60Hz |
| Chauffeur ic | COF Built-in 1 source chips |
| Panel Gewiicht | 800g (Typ.) |
| Signal Interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Input Volt | 12.0V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 65 °C |
| Panel Modell | LSC320AN09-H |
| Panel Typ | a-Si TFT-LCD , CELL |
| Pixel Format | RGB Horizontal Stripe |
| bezel Ouverture | - |
| Uewerfläch | Antiglare (Haze 2%), Hard coating (2H) |
| Kontrast Verhältnis | 4000:1 (Typ.) (TM) |
| Display Modus | SVA, Normally Black, Transmissive |
| Äntwert Zäit | 20 (Typ.)(G to G) |
| transmissivitéit | 6.9% (Typ.)(with Polarizer) |
| Lampe Typ | No B/L |
| Touchscreens | Without |
| Applikatioun | TV Sets |
