| Part Number | LS055R3SX01 |
| Mark | Sharp |
| Gréisst | 5.5 |
| Applikatioun | Mobile Phone |
| Opléisung | 1536×2560 |
| Zesummesetzung | CG-Silicon , LCM |
| Hellegkeet | |
| CR | 1280:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Mark | Sharp |
| diagonal Gréisst | 5.5 inch |
| Pixel Format | 1536(RGB)×2560 546PPI |
| aktiv Beräich | 71.424(H)×119.04(V) mm |
| luminance | 460 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 16.7M 70% NTSC |
| Gewiicht | 21.1g |
| Frame Taux | 60Hz |
| Interface Typ | MIPI (4 data lanes) , 32 pins Connector |
| Stroumversuergung | 1.8/5.5/-5.5V (Typ.)(IOVDD/VSP/VSN) |
| Ëmwelt | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| Modell | LS055R3SX01 |
| Typ | CG-Silicon , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 73.824(H)×126.44(V) ×1.4(D) mm |
| Kontrast Verhältnis | 1280:1 (Typ.) (TM) |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Betribssystemer Modus | New Mode2, Normally Black, Transmissive |
| Liichtquell | WLED [8S2P] , W/O Driver |
| entworf fir | Mobile Phone |
| Touch Panel | Without |
