| Part Number | LS029B3SX04 |
| Mark | Sharp |
| Gréisst | 2.9 |
| Applikatioun | HMD VR AR |
| Opléisung | 1440×1440 |
| Zesummesetzung | LCM , CG-Silicon |
| Hellegkeet | |
| CR | 600:1 |
| Faarwen | 16.7M |
| Géigeliicht | 2 strings WLED , No Driver |
| Interface | MIPI |
| Fabrikant beschwéiert | Sharp |
| Modell Numm | LS029B3SX04 |
| Écran Gréisst | 2.9 inch |
| Écran Typ | LCM , CG-Silicon |
| Pixel Zuel | 1440(RGB)×1440 705PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 51.84 × 51.84 (H×V) |
| Kontur (mm) | 54.24 × 59.02 × 1.51 (H×V×D) |
| luminance | 150 cd/m² (Typ.) |
| Kontrast Verhältnis | 600 : 1 (Typ.) (TM) |
| Vue Wénkel | - |
| Äntwert | 4.6/3.5 (Typ.)(Tr/Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | SFR, Normally Black, Transmissive |
| Faarfdéift | 16.7M 70% NTSC |
| mass | 7.20g (Typ.) |
| benotzt fir | HMD VR AR |
| Erfrëschungsrate | 120Hz |
| touchscreen | Without |
| Signal Typ | MIPI (2 ch, 4 data lanes) , 40 pins Connector |
| Spannungsversuergung | 1.8/5.5/-5.5V (Typ.)(VDDI/AVDD/AVEE) |
| max. Bewäertungen | Storage Temp.: -30 ~ 70 °C Operating Temp.: -20 ~ 60 °C |
