| Part Number | LQ800D3HA01 |
| Mark | Sharp |
| Gréisst | 80 |
| Applikatioun | TV Sets |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD, CELL |
| Hellegkeet | |
| CR | 5000:1 |
| Faarwen | 1.07B |
| Géigeliicht | No |
| Interface | LVDS |
| Panel Mark | Sharp |
| Panel Modell | LQ800D3HA01 |
| Panel Gréisst | 80" |
| Panel Typ | a-Si TFT-LCD, CELL |
| Resolutioun | 1920(RGB)×1080, FHD, 27PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 1771.2(W)×996.3(H) mm |
| bezel Ouverture | - |
| Kontur Gréisst | 1802.6(W)×1026.9(H) ×1.7(D) mm |
| Uewerfläch | Antiglare (Haze 3%), Hard coating (2H) |
| Hellegkeet | 0 cd/m² |
| Kontrast Verhältnis | 5000:1 (Typ.) (TM) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10) |
| Display Modus | ASV, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 4 (Typ.)(G to G) |
| Glas Déift | - |
| transmissivitéit | 6.51% (Typ.)(with Polarizer) |
| weisen Faarwen | 1.07B 73% NTSC |
| Lampe Typ | No B/L |
| Frequenz | 120Hz |
| Touchscreens | Without |
| Chauffeur ic | COF Built-in 16 source + 10 gate chips |
| Panel Gewiicht | 7.80g (Typ.) |
| Applikatioun | TV Sets |
| Signal Interface | LVDS (4 ch, 10-bit) , 92 pins Connector |
| Input Volt | 12.0V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
