| Part Number | LQ125T1JW02 |
| Mark | SHARP |
| Gréisst | 12.5 |
| Applikatioun | NBPC |
| Opléisung | 2560×1440 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | SHARP |
| Panel Modell | LQ125T1JW02 |
| Panel Typ | IGZO TFT-LCD , LCM |
| Panel Gréisst | 12.5 inch |
| Resolutioun | 2560(RGB)×1440 , Quad-HD |
| Display Modus | Normally Black, Transmissive |
| Uewerfläch | |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLED |
| Signal Interface | eDP (4 Lanes) |
| rohs: | |
| Applikatioun | NBPC |
