| Part Number | LPM089A128A |
| Mark | JDI |
| Gréisst | 8.9 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1536×2048 |
| Zesummesetzung | LTPS TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Mark | JDI |
| Modell | LPM089A128A |
| diagonal Gréisst | 8.9 inch |
| Typ | LTPS TFT-LCD, LCM |
| Pixel Format | 1536(RGB)×2048 [QXGA] 288PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 135.245(H)×180.326(V) mm |
| kontur dim. | 140.85(H)×190.75(V) mm |
| bezel Beräich | - |
| Behandlung | Hard coating (3H) |
| luminance | 420 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 30 (Max.)(Tr+Tf) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10) |
| Betribssystemer Modus | IPS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 71% NTSC |
| Liichtquell | WLED [7S4P] , W/O Driver |
| Gewiicht | 90.26g |
| entworf fir | Pad & Tablet |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | MIPI (2 ch, 4 data lanes) , 51 pins Connector |
| Stroumversuergung | 1.8/3.8V (Typ.)(IOVDD/AVDD) |
| Ëmwelt | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
