| Part Number | LP156WF9-SPN1 |
| Mark | LG Display |
| Gréisst | 15.6 |
| Applikatioun | Laptop |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | LG Display |
| Panel Gréisst | 15.6" |
| Resolutioun | 1920(RGB)×1080, FHD, 141PPI |
| Affichage Beräich | 344.16(W)×193.59(H) mm |
| Kontur Gréisst | 350.66(W)×205.8(H) ×4.4(D) mm |
| Hellegkeet | 300 cd/m² (Typ.) |
| Vue Wénkel | 80/80/80/80 (Min.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 262K 99% sRGB |
| Frequenz | 60Hz |
| Form Stil | Slim (PCBA Bent, T≤3.0mm) |
| Signal Interface | eDP (2 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , 30 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Modell | LP156WF9-SPN1 (LGD05A8) |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Glare (Haze 0%) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Display Modus | IPS, Normally Black, Transmissive |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Lampe Typ | WLED , 12K hours , With LED Driver |
| Touchscreens | Without |
| Applikatioun | Laptop |
