| Part Number | LP154WX4-TLB2 |
| Mark | LG Display |
| Gréisst | 15.4 |
| Applikatioun | NBPC |
| Opléisung | 1280×800 |
| Zesummesetzung | LCM |
| Hellegkeet | 220 |
| CR | 400:1 |
| Faarwen | 262K |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | LG.Philips LCD |
| Panel Modell | LP154WX4-TLB2 15 Compatible model |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 15.4 inch |
| Resolutioun | 1280(RGB)×800 , WXGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 331.2×207 mm |
| skizzéieren | 344×243.5×6.5 mm |
| Form Stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Uewerfläch | Glare (Haze 0%), Hard coating (2H) |
| Hellegkeet | 220 cd/m² (Typ.) |
| Kontrast Verhältnis | 400:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193145% |
| Äntwert Zäit | 8 (Typ.)(Tr+Td) |
| Vue Wénkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 1 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| LP154W01-A3 | LG Display | 15.4 | 1280×800 |
| LP154W02-B1K2 | LG Display | 15.4 | 1680×1050 |
| LP154WP2-TLA1 | LG Display | 15.4 | 1440×900 |
| LP154WP3-TLA2 | LG Display | 15.4 | 1440×900 |
| LP154WP4-TLA1 | LG Display | 15.4 | 1440×900 |
| LP154WU1-TLA2 | LG Display | 15.4 | 1920×1200 |
| LP154WU1-TLB1 | LG Display | 15.4 | 1920×1200 |
| LP154WX4-TLA1 | LG Display | 15.4 | 1280×800 |
| LP154WX5-TLB2 | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLP1 | LG Display | 15.4 | 1280×800 |
| B140XTN02.3 | AUO | 14.0 | 1366×768 |
| CLAA121UA01CW | CPT | 12.1 | 1600×900 |
| HSD110PHW1-A00 | HannStar | 11.0 | 1366×768 |
| LP125WH2-TLB1 | LG Display | 12.5 | 1366×768 |
| LP156WD1-TLB1 | LG Display | 15.6 | 1600×900 |
| LP173WF3-SLB2 | LG Display | 17.3 | 1920×1080 |
| LTN106W1-L01 | Samsung | 10.6 | 1280×768 |
| LTN156KT01-003 | Samsung | 15.6 | 1600×900 |
| N133B6-L02 | Innolux | 13.3 | 1366×768 |
| N140BGE-L21 | Innolux | 14.0 | 1366×768 |
